554435 – VCMA-20ULST (115V)

Click to rate this post!

[Total: 0 Average: 0]

The VCMA-20 is ideal for automatic collection and removal of condensate from air conditioning, refrigeration and de-humidification equipment when gravity drainage is not possible or practical.

Item:	554435
Model:	VCMA-20ULST (115V)

Ratings
HP	1/30 hp
Frequency	60 Hz
Amps – Full Load	1.5 A
Full Load Watts	93 W
Volts	115 VAC
Cord Length	6 ft
Maximum Flow Rate – 60Hz	1.33 gpm / 80 gph
Max PSIG	8.7 PSI
Shut-Off	20 ft
Safety Switch	Yes
Tank Capacity	0.5 gal
Liquid
Max Fluid Temperature	140 °F

Materials of Construction
Pump Base Material	Plastic
Pump Body Material	Plastic
Impeller Material	GF Polypropylene
Check Valve	Yes
Installation
Discharge Type	Barb
Discharge	0.38 “
Product Length	11 “
Product Width	5 “
Product Height	7 “
Pump Length	11 “
Product Weight	5.5 lb
Product Weight w/ Pack	6 lb
Carton Length	12 “
Carton Width	7.44 “
Carton Height	7.13 “
Tubing Included	Yes
Other
Minimum Order Quantity	1
Accessories / Repair Kits	Tank 154401 Cover, Motor 154421 Float Arm 154452 Switch Holder 154471 Switch 950337 T-20/25 ne carton of 25 pieces of 20′ (6.01m) length 3/8″” (9.5 mm) ID VC tubing 599033 T-3/8 100′ (640.1 m) of 3/8″” (9.5 mm) ID x1/2″” (12.37 mm) OD clear tubing 599107 CV-10 1/4″” FNPT (6.35 mm) to 3/8″” (9.5 mm) ID vinyl tubing 599065 CV-14/24 1/4″” MNPT (6.35 mm) to 3/8″” (9.5 mm) OD rigid plastic or copper tubing 599069 CV-15/20 1/4″” MNPT (6.35 mm) to 3/8″” (9.5 mm) OD rigid plastic or copper tubing 599033 Check Valve 3/8″” NPT x 1/4″” OD 154708
Electrical Agency Approvals	CSA/UL
Standard Warranty	12 Months
