The XS Series was designed with performance, serviceability and reliability in mind.
| Item: | 69040309101 |
| Model: | XS439-HBVM-CW |
Stock: Call for availability
Technical support: Yes
Shipping time: Same day
Shipping: USA and Canada
Talk to a pump specialist now: (303) 699-7845
Get a Fast Quote from a Pump Specialist
The XS Series was designed with performance, serviceability and reliability in mind.
| Item: | 69040309101 |
| Model: | XS439-HBVM-CW |
Ratings |
|
| Frequency | Not Applicable |
| Phases | Not Applicable |
| Volts | Not Applicable |
| Stages | 1 |
| Motor Enclosure | Not Applicable |
| Rotation | Clockwise facing the shaft |
Liquid |
|
| Maximum Fluid Temperature | 212 °F |
Materials of Construction |
|
| Pump Body Material | Cast Iron |
| Pump Volute Material | Cast Iron |
| Impeller | Closed |
| Impeller Material | Cast Iron |
| Seal Material | Carbon/Ceramic, Nitrile |
| Seal | Mechanical Seal |
Dimensions |
|
| Discharge | Grooved |
| Discharge Diameter | 3 “ |
| Suction Diameter | 4 “ |
| Suction | Grooved |
| Pump Length | 23.33 “ |
| Product Weight | 145 lb |
| Pump Height | 15.38 “ |
| Pump Width | 14 “ |
| Hydraulic Fit | B |
Other |
|
| Warranty Standard Time | 12 Months |
