Stock: Call for availability
Technical support: Yes
Shipping time: Same day
Shipping: USA and Canada
Talk to a pump specialist now: (303) 699-7845
Get a Fast Quote from a Pump Specialist
|
Fig. No. |
Part Description |
FAOT-4 |
FAOT-5 |
FAOT-6 |
Materials of Construction |
|---|---|---|---|---|---|
|
1 |
FAOT Volute Case |
305453001 |
305453015 |
305453016 |
Cast iron, ASTM-A48 CL30 |
|
2 |
FAOT Impeller |
305717002 |
305453053 |
305453054 |
Cast iron, ASTM-A48 CL30 |
|
3 |
FAOT Transmission Housing |
305453003 |
305453055 |
Cast iron, ASTM-A48 CL30 |
|
|
5 |
FAOT Shaft/Bearing Assembly |
305453004 |
Misc. |
||
|
30 |
FAOT Retaining Ring |
305463027 |
Steel |
||
|
35 |
FAOT Shaft Key |
305463028 |
301 stainless steel |
||
|
90 |
FAOT Mechanical Shaft Seal |
305463029 |
Carbon/ceramic/nitrile – stainless steel |
||
|
100* |
FAOT Gasket |
305453007 |
305453024 |
NA60 |
|
|
100A |
FAOT O-ring |
305463251 |
305463252 |
Nitrile |
|
|
503 |
FAOT Water Slinger |
305453005 |
Neoprene |
||
|
500 |
FAOT Pipe Plug (3-pack) |
305463020 |
CAD-plated steel |
||
|
530C |
FAOT Hex Nut (8-pack) |
305463033 |
Zinc-plated steel |
||
|
530D |
FAOT Lock Washer (6-pack) |
305463032 |
Zinc-plated steel |
||
|
531 |
FAOT Stud (4-pack) |
305463129 |
Zinc-plated steel |
||
