| Fig. No. | Part Description | Part No. | Materials of Construction | |||
|---|---|---|---|---|---|---|
| FBSEF-500 | FBSEFL-075 | FBSEF-750 | FBSEFL-100 | |||
| 1 | Pump Case includes Studs, Lock Washers, and Nuts | 305460002 | Cast Iron, ASTM-A48 CL30 | |||
| 2 | Impeller | 305715005 | 305715006 | Cast Iron, ASTM-A48 CL30 | ||
| 3 | Motor Adaptor | 305715009 | Cast Iron, ASTM-A48 CL30 | |||
| 12 | Mech Seal Shaft Sleeve | 305458011 | 416 Stainless Steel | |||
| 35 | Shaft Key | 305451003 | 301 Stainless Steel | |||
| 90 | Mechanical Shaft Seal | 305463043 | Carbon/Ceramic x FKM-SS | |||
| 100A | O-Ring | 305463296 | FKM | |||
| 200 | Replacement Motor JM Frame | (See Motor Specifications) | Misc. | |||
| 500 | Pipe Plug 3/4″NPT (3-Pack) | 305463050 | Zinc-plated Steel | |||
| 503 | Water Slinger | 305453030 | Neoprene | |||
| 510 | Impeller Hex Bolt | 305463077 | 416 Stainless Steel | |||
| 520 | Impeller Washer | 305463187 | 303 Stainless Steel | |||
| 530A | Hex Cap Screw – Motor (12-Pack) | 305463010 | Zinc-plated Steel | |||
| 530B | Lock Washer, Pump Case (4-Pack) | 305463135 | Zinc-plated Steel | |||
| 530C | Hex Nut, Pump Case (4-Pack) | 305463033 | Zinc-plated Steel | |||
| 530D | Lockwasher – Motor Adaptor (8-Pack) | 305463135 | Zinc-plated Steel | |||
| 531 | Stud (4-Pack) | 305463129 | 300 series Stainless Steel | |||
Pre-May 2019
| 1 | Pump Case | N/A | Cast Iron, ASTM-A48 CL30 |
| 100A | Gasket, Case | 305463126 | Vegetable Fiber |
