Utilizing a sealed, submersible pump with a large reservoir collection tank, the 3-ABS also includes a durable galvanized steel tank cover to accommodate higher-flow drain periods or cycling. It is an ideal choice for a self-contained, high volume, high head condensate removal pump. An integrated, unique float switch design assures reliability and security while providing easy access to the float for servicing.
A shallow pan condensate removal pump designed for in-pan placement, the 3-ABS offers next-generation technology for air conditioner condensate removal. The pump is totally submersible with a built-in, advanced non-mercury mechanical switch that automatically triggers operation when condensate in the pan or reservoir reaches a preset level. Then, automatic shutoff occurs when the condensate level drops. Low weight, compact size, high lift, and quiet operation make the Little Giant line of ABS pumps perfect for in-pan condensate and other condensate removal.
| Capacity | 310 gph @ 1′ |
| Shut Off | 26′ (7.9 m) |
| Max. Liquid Temp. | 120 °F (49 °C) |
| Discharge | 1/2″ (12.7 mm) MNPT |
| Impeller | Nylon |
| Electrical | 115 V, 60 Hz, 3.5 A 230 V, 50/60 Hz, 1.8/1.6 A |
| Operation | Automatic |
| Head | GPH (LPH) |
| 1′ | 310 (1175) |
| 3′ | 290 (1099.1) |
| 5′ | 280 (1061.2) |
| 10′ | 250 (947.5) |
| 20′ | 110 (417) |
| Item | Model | Volts | Shut-Off | Safety Switch | Tubing Included |
|---|---|---|---|---|---|
| 551320 | 3-ABS | 115 VAC | 26 ft | No | No |
