510802 – 10EC-CIA-SFS

The Duplex Alarm System/Pump Control provides residential and commercial customers with a reliable means of controlling a duplex (two pump) system in a water or sewage installation. The system consists of a control panel and three sensor floats. The non-corrosive, indoor and /or outdoor enclosure comes pre-assembled. The panel exterior features a large red alarm beacon. An exterior buzzer test/normal/silence switch allows the 83-85db audible alarm buzzer to be silenced or testing of buzzer and light to ensure proper operation of alarm function.



Item: 510802
Model: 10EC-CIA-SFS



Ratings
HP 1/2 hp
Frequency 60 Hz
Phase Single-Phase
Amps – Full Load 6.5 A
Amps – Starting 14.5 A
Full Load Watts 750 W
Volts 115 VAC
Cord Length 20 ft
Pump Power Cord Type SJTW
Pump Power Cord Gauge 18-3
Motor Type Submersible
Continuous Duty Yes
Thermal Overload Protection Yes
Maximum Flow Rate – 60Hz 67 gpm / 4020 gph
Minimum Flow Rate – 60Hz 5 gpm / 300 gph
Shut-Off 36 ft
Minimum Head – 60Hz 5 ft
Shut Off Height – 60Hz 36 ft
Stages 1
Max Solid Handling Size 0.5 “
Switch Type Integral Snap-Action Float
Motor Cooling Oil

Liquid
Max Fluid Temperature 140 °F

Materials of Construction
Pump Base Material Plastic
Pump Body Material Cast Iron
Pump Volute Material Polypropylene
Impeller Type Non-Clog
Impeller Material Nylon
Motor Shaft End – Material SAE 1040/45 Carbon Steel
Intake Screen Material Nylon
Fasteners Material Stainless Steel
Top Bearing Material Steel
Top Bearing Type Ball
Bottom Bearing Material Steel
Bottom Bearing Type Ball Bearing
Seal Material Carbon/Ceramic, Nitrile
Seal Type Mechanical Seal

Installation
Discharge Type Threaded – FNPT
Discharge 1.5 “
Product Length 10.66 “
Product Width 8.48 “
Product Height 11.28 “
Pump Length 10.66 “
Product Weight 29 lb
Product Weight w/ Pack 30 lb
Carton Length 10.83 “
Carton Width 9.45 “
Carton Height 13.39 “
Off Level – Range 2″ – 5″
On Level – Range 8″ – 11″

Other
Accessories Included None
Minimum Order Quantity 1
Electrical Agency Approvals CSA
Standard Warranty 12 Months
